Vapcell T39 21700 3900mah 35A/50A

$ 0.00
Brand Vapcell
Series 21700
Model T39
Color red
Weight 72g
Chemistry INR
Type flat top

Vapcell T39 21700 3900mah 35A/50A


u Model: T39

u Size: 21.1±0.2 * 70.5±0.3mm

u Typical Capacity: 3900mAh (0.2C discharge)

u Min capacity: 3800mAh (0.2C discharge)

u Nominal voltage: 3.60V

u Max Continuous Discharge Current: 35A

u Max Discharge Current: 50A

u End-of-charge voltage: 4.20V

u End-of-discharge Voltage: 2.5V

u Weight: 68g ( Appr)

u Internal resistance: 6mΩ ( Appr) AC 1kHz

u Standard Charge: 3000mA,CCCV 100mA cut-off

u Quick Charge Current: 6000mA


Button top can be added, and the size is 2-3mm longer than a standard 21700 cell like flat top & unprotected. The button top is widely required for flashlights, doorbells and other devices.

Discharge Graph:

T39-2.bmp-3.bmpT39- 1.jpgT39- 2.jpgT39- 4.jpgT39- 3.jpgT39- 5.jpg
