Vapcell 21700 F63 6250mAH
Vapcell F63 21700 6250mah 12.5A
Tips：
Button top can be added, and the size is 2-3mm longer than a standard 26650 cell like flat top & unprotected. The button top is widely required for flashlights, doorbells and other devices.
Specification:
Model | INR21700 |
Size | ⌀21.6±0.2*71.0±0.3mm |
Nominal voltage | 3.60V |
End-of-charge voltage | 4.20V |
End-of-discharge Voltage | 2.50V |
Typical Capacity | 6250mAh (0.2C discharge) |
Min capacity | 6050mAh (0.2C discharge) |
Weight | Max:74g |
Internal resistance | Max:16mΩ （AC 1kHz） |
Standard Charge | 2000mA,CC,CV 100mA cut-off |
Quick Charge Current | 3500mA |
Max Continuous Discharge Current | 12500mA（12.5A） |
Cycle Life | 1C discharge/ 70% capacity, ≥1000 cycles |
Operating Temperature | Charging, 0°C ~ 45°C |
Discharging, -20°C~70°C | |
Storage Temperature | -5°C~35°C |
Storage Humidity | ≤75%RH |
Appearance | Without scratch,distorion,contamination, |
and leakage | |
Standard environmental condition | Temperature: 23±5°C |
Humidity :45-75%RH | |
Atmospheric Pressure :86-106KPA | |
